266

small nominal diameter - high pressures

design

2/2-way

type of operation

directly controlled

nominal diameter

2.0 mm - 6.0 mm

pressure range

0.00 - 100.0 bar (see table)

Kv value

2.5 - 9.5 l/min

housing material

Nickel-plated steel, Galvanized steel

sealing material

Sealing material, static

FKM

Dynamic sealing material

seat seal

PTFE

screen material

mesh size

opening pressure

Ambient temperature

-10 to +50°C

Temperature Medium

-10 to +100°C

connection

G1/4, G3/8

Electrical connection

Device socket according to DIN EN 175301-803 Type A, for AC operation with integrated rectifier

connection voltage

230V 50Hz, 24V DC, Special voltages

voltage tolerance

± 10%

power consumption

see detailed table

duty cycle

100% ED

degree of protection

IP 65 with mounted device socket

installation position

any

Tables/charts

DN [mm]	Pressure [bar]	connection	Kv value [l/min]	power consumption [W]		Weight - Brass [kg]
				24V DC	230V 50Hz
2	0–100	G1/4; G1/8	2,5	35	41	1,7
3	0–40	G1/4; G1/8	3,7	35	41	1,7
4	0–20	G1/4; G1/8	6,5	35	41	1,7
5	0–16	G1/4; G1/8	8,0	35	41	1,7
6	0–10	G1/4; G1/8	9,5	35	41	1,7
